Small Sachet Packing Machine For Tablets/Capsules

FOB Reference Price:Get Latest Price
$1,000.00 - $4,800.00 / Set | 1 Set/Sets (Min. Order)
Power:
50HZ,1.2KVA
Model Number:
DS-200A
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Report Suspicious Activity
Overview
Quick Details
Warranty:
More than 5 years
Application:
Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Material:
Plastic
Type:
Multi-Function Packaging Machine
Condition:
New
After-sales Service Provided:
Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support, Engineers available to service machinery overseas
Place of Origin:
Guangdong, China
Brand Name:
Dession Machinery
Voltage:
220V
Function:
Filling, Labeling, Sealing, Wrapping
Automatic Grade:
Automatic
Certification:
CE
Packaging Type:
Bags, Foil, Pouch
Driven Type:
Electric
Dimension(L*W*H):
(L)640*(W)700*(H)1580
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
Packaging Film Material:
Laminated film
Packaging Rate:
30~80bags/min
Measuring Form:
Metering cups
Sealing Form:
3/4 sides sealing
Transverse Sealing:
Netted Line/Straight Line
Cutting:
Tooth Cut/Flat Cut
Packing machine:
Small Sachet Packing Machine For Tablets/Capsules
Optional devices:
Printer,Linked bag device,Puncher
Keyword:
Tablet Packing Machine
Supply Ability
Supply Ability:
130 Set/Sets per Month
Packaging & Delivery
Packaging Details
Standard Exported Wooden Case for Small Sachet Packing Machine For Tablets/Capsules
Port
Foshan/ Guangzhou
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated

Small Sachet Packing Machine For Tablets/Capsules

Product Description





 sigle piece.jpg



  Automatic packaging machine    Function

1. The section where the material contact is stainless steel as the body of machine is optional for complete or partial  stainless steel and all out equipments have passed the CE Standard.

2. Computer controller is the first patent of China; inverter and power switch are all imported with advanced technology.

3. Optional English or Chinese screen display, easy and simple operation.



QQ20160409104207



4. High-sensitivity photoelectric color tracing and digital input of cutting position get more accuracy.



photo cell

5. Embedded sealing , enhanced structure of heat sealing intelligent temperature controller and excellent heat balance make all kinds of packaging materials possible with good performance, low noise, clear cutting pattern and strong sealability.

6. Packaging speed and length of bags can be set to some extent without further adjustment and parts changing. Packaging speed and length of bags can be set to some extent without further adjustment and parts changing.

7. Equipped with rolled plate device enables volume of packing changing anytime, loss reducing and improve productivity.

 tablet feeding2 .jpg



8. Alarming function for specific output; automatic display of packaging speed.

9. Optional coding equipment and with 1 to 3 lines for batch number and expiration date.

10. Bag-making, filling, sealing, cutting, counting, thermal pressing of batch number can be achieved automatically and straightly.

11. Flat cutting, pattern cutting, linking cutting can be realized by changing the tools;easy operation with smooth bags.

12. Bag-making equipment can be changed according to specific requirement of customers and products.



 packaging machine   Specification



Brand

Dession Packaging Machinery

Type

DS-200A

Measurement

Cup Metering

Sealing Style

Three- edge-sealing/Four-edge-sealing

Horizontal Sealing

Netted Line / Straight Line

Cutting

Tooth Cut / Flat Cut

Measurement Range

1~100ml

Packaging Rate

30~80 bags/min

Bag Width

15~100mm

Bag Length

30~180mm

Film Roll Width

30~220mm

Film Roll Diameter

300mm

Bag Pulling

Stepping Motor Bag Pulling

Power

220V,50HZ,1.2KVA

Machine Size

(L)640×(W)700×(H)1580

Machine Weight

300KG

Optional Device

Date Code Printer

Gas-Filling Device

Punching Device

Machine Wrapping

Wooden Case





Application  of   packaging machine

Suitable for puffed food, candy, peanut, melon seeds, rice, seeds, monosodium glutamate, corn particles, the flake, solid materials and milk powder, washing powder such as packaging.



 Advantage

1.Well and High Quality Control
2.Competitive Prices
3.Small Order Acceptable
4.ODM Accepted
5.OEM Accepted
6.Tailor-made Product







Packaging & Shipping

Being packed by strech wrapping film as inner and wooden case as outer.

packing & shipping





Our Services

12 months warranty,lifetime maintenance.





Company Information



office workshop

Customer View

feedback from USA customer



Wecome to visit our factory for discusing business.





FAQ

Q1  For the control panel,how many languages are available?

A1 Usually,English and Chinese are available,if you would like to have other language,pls let us know in advance



Q2 What’s material of machine?

A2 Carbon steel and stainless steel are available.

Q3 What’s the material for conctacted parts of machine?

A3 Stainless steel



Q4 What kind of packing film can be used?

A4 Complex film roll,such as OPP/CPP,CPP/PE,MST/PE/PET/PE.



Q5 What is your advantage?

A5 1.Stable and reliable performance of machine,

2. As a leading manufacturer,we can give competitive price.

3. To reply your enquiry promptly.

3. Low price of spare parts.

4. In case some malfunction,we promptly offer on-line service, such as E-mail, skype, wechat,viber, whatsapp to supply videos,pictures,
